Welding Plans For Fun and Profit

welding plans

Our new welding plans are perfect for beginning and advanced projects.

These welding blue prints and directions are all original. No copycat plans or drawings you can find on the internet or in the public domain.

Our welding plans and instructions include:
  • Clear, easy to follow step by step instructions describing how, what, and where to weld and fabricate each project.

  • Either photos of the actual project being fabricated, or jpeg images of the 3D CAD models of the project.

  • Detailed fabrication drawings that will be referred to in the instructions. All drawings will include weld symbols according to AWS standards. The weld symbols will be explained in the instructions (ie. a glossary of weld symbols with descriptions).

  • A complete bill of materials / cut list of materials. This will included any fasteners as required

Everything is in PDF so anybody with Acrobat Reader can view and print the plan set/instructions. Adobe Reader is Free.

All welding plans are written with the beginner in mind, but most of the plans will be fun and challenging for most intermediate and advanced welders. This way anybody can understand how to proceed with the project.

In addition, you can create as many welding projects from these plans as you want for fun, or sell your completed project for a profit!

welding project plans


GUARANTEE: If you are not satisfied with the plans for any reason at all just send us an email along with your receipt number and tell us why and we will refund your money. All we ask is that you do so within 30 days. Fair enough?


go kart plansGo Kart Welding Plans (Frame) -- 23 page step by step guide $29.99 $4.95.

MATERIALS REQUIRED:
(42 FT) Round Tubing, 1.00” O.D. X .058” wall
(2 ½” X 6”) Mild steel sheet, 11 GA
(4” X 8”) Mild steel plate, ¼”
(4” X 12”) Mild steel sheet, 14 GA
(23” X 22”) Mild steel sheet, 16 GA

Add to Cart


low boy oil panLow Boy Oil Pan Welding Plans -- 14 page step by step guide $19.99 $3.95.

MATERIALS REQUIRED:
(28 in x 26 in) Mild steel sheet, 16 GA
(3in x 1 ½ in) Mild steel sheet, 14 GA
(1 ¼ in x ½ in x 1 ¼ in long) Mild steel rectangular barstock
(37 in) Mild steel round barstock, ½” dia.
(3 in) Continuous hinge, .06 in thick x approx 2 in open width x 1/8” dia pin.
(2) Swiveling casters, 2 in dia. Wheels
(2) Caster wheels, 3 in dia.
(4) SAE washers, ½”
(2) Cotter pins, 1/8 in x 1 ¼ in long
Suggested: (1) Brass Ball valve, ½” NPT female – ½” NPT m

Add to Cart


garden benchGarden Bench Plans --17 page step by step guide $19.99 $3.95.

MATERIALS REQUIRED:
(17 ft) Mild steel rect. tube, 1” X 2” X 16 GA
(15 ft) Steel barstock/strap, 1” X 1/8”
Mild steel sheet, 1” X 8” X 16 GA
Mild steel sheet, 4” X 12” X 11 GA
(26) Screws, Flat-head, self-tapping, #10 X 1 ¼” long
(4) Screws, flat-head machine, #10-24 UNC X 1 ¼” long
(4) Dome nuts, #10-UNC

Add to Cart


fire pitCustom Fire Pit Plans --11 page step by step guide $19.99 $3.95.

MATERIALS REQUIRED:
(3 FT X 5 ½ FT) Mild steel plate, 10 GA (.134)
(4in X 12 in) Mild steel sheet, 11 GA or 1/8”
(4) Angle section, 2” x 2” x 3/16”
(14 ft) Mild steel rod, ½” diameter
(105 ft) Mild steel rod, ¼” diameter

Add to Cart


hand truckHand Truck Welding Plans -- 15 page step by step guide $19.99 $3.95.

Materials Required:

(28 FT.) Round Steel tubing, ¾” dia. X 16 GA
(2 IN) Round Steel Tubing, 7/8” dia. X 16 GA
Mild steel plate, ¼” x 21” x 18”
(18 ½ IN) Round Steel Barstock, 5/8” dia.
(2) Wheels, steel rimmed with rubber tire, 8” dia. x 2” wide (offset rim)
(4) SAE Washers, 5/8”
(2) Cotter pins, 1/8” x 1 ¼”
Scrap wood or a length of 1” x 2” pine or similar wood.

Add to Cart


storage shelf plansStorage Shelf Plans (8ft) -- 12 page step by step guide $19.99 $3.95.

Materials Required:

(26 FT) Steel square tube, 1” x 1” x .065 wall
(75 FT) Steel angle, 1” x 1” x 1/8”
(8 FT) Steel rectangular tube, 1” x 2” x .065 wall
(1 1/3 Sheet) Partical board, 1/2”
(4) Hex Nut, ½-13 UNC
(4) Hex Head Cap Screw, ½-13 x 1 ½” long, GR-8
(1 Box) Self-tapping screws, 8-18 x 1” long

Add to Cart


work benchWork Bench Welding Plans -- 14 page step by step guide $19.99 $3.95.

Materials Required:

(34 ft) Steel angle, 2” x 2” x 3/16”
(13 ft) Steel angle, 3” x 3” x ¼”
1” Plywood, MDF, or Particle board (4’ x 8’ sheet)
(20) #10 sheet metal screws, flat head
(4) Leveling feet

Add to Cart


welding cartWelding Cart Plans -- 13 page step by step guide $19.99 $3.95.

Materials Required:

(20 FT) Square steel tube, 1” X 1” X 16 GA
(15 3/16 IN) Round Steel Tube, ¾” X 16 GA
(27 IN X 24 IN) Mild steel sheet, 16 GA.
(2) Swivel casters with plate mounting
(2) Wheel, 8” x 2 ¼”, steel rim with rubber tire
(4) SAE Washer, 5/8”
(2) Cotter pin, 1/8” x 1 ¼”
(15 1/2 IN) Steel barstock, 5/8”

Add to Cart


tool rack plansTool Rack Plans -- 9 page step by step guide $19.99 $3.95.

Materials Required:

(6 ½ FT) Steel angle, 1 ½” x 1 ½” x 1/8”
(6 FT) Steel square tube, 1” x .065 wall
(2 ½ FT) Steel round barstock, ½”
(4) Industrial equipment feet. Approximately 1 ½” dia. X 1” ht.
Steel sheet, 16 GA, 23 ½” x 14 ½”

Add to Cart


tomato cage plansTomato Cage Welding Plans -- 12 page step-by-step guide $19.99 $3.95.

Materials Required:

(30 ft) ¼” diameter mild steel rod.
½” plywood, particle board, MDF, or similar wood. At least 18” x 48”.
(3) 1” x 2” x 3” wood blocks

Add to Cart

SAVE $20.55!

As you can see, all the welding plans are valued at $209.90. But we are offering them individually at discounted prices. However, if you bought them all at the lowest discounted prices above (and they are going up) it would be $40.50. But we bundled them all together into one 138 page manual called Killer Welding Projects Vol. 1 and priced them at just $19.95 (this price will go up soon as well).

Order Killer Welding Projects Vol. 1 Which Includes
All The Welding Project Plans Above
For Just $29.95!

Add to Cart

View Cart
